LTE Distributed base station system is equipped with 2*250mW/2*10W/2*20W RF remote head end supporting main frequency B1/B3/B5/B8/B28 or customized band.
The baseband unit (BBU) is connected to the EPC core network through IPsec (IPRAN), and the system adopts a star network architecture to provide FDD-LTE services to users.
The system design achieves quick deployment and network construction, providing small cell coverage and improving indoor coverage, capacity with low cost.
HIGHLIGHTS
・Support GPS,RGPS, 1588 synchronization
・Supports 64 user access status and 32 user VOLTE, providing voice, video, data and mobile communication services for terminals
・Supports multiple IP network backhaul solutions such as xPON/PTN/IPRAN
・Supports PSK authentication, digital certificate authentication, and ESP encrypted transmission
・Supports SON, remote management, and TR069 network management functions
・Support AC/DC power supply
・Antennas can be installed externally or in an integrated manner
4G PON Base Station is a distributed base station based on PON network, which is mainly composed of two parts: 4G baseband unit (4G BBU) and remote unit (4G pRU). This base station utilizes time-division forward transmission technology to solve the problem of Point-to-Multipoint uplink aggregation transmission between BBU and RU links.
The baseband unit is used for processing the physical layer and upper layer protocol stack of the wireless access network air interface, as well as operation and maintenance processing, to achieve air interface communication with terminals and connection with the core network; And the downlink distribution and uplink aggregation of communication data from remote units to achieve extended functionality.
The remote unit is responsible for RF transmission and reception, using low-power signal transmission to quickly achieve distributed coverage of 4G signals.
HIGHLIGHTS
・Point to multipoint patented technology
・BBU is centrally deployed in the end office data center
・BBU supports IPRAN/IPSCE backhaul
・BBU-RU multiplexing PON network optic fiber cables
・Single cell+single channel PON, support 7*pRU (24dBm)
・RU supports a maximum carrier bandwidth of 20MHz
・The farthest transmission is 7km between BBU and RU
・Support GPS,RGPS, 1588 synchronization
・Supports 2*64 user access status and 2*32 user VOLTE, providing voice, video, data and mobile communication services for terminals
・Supports PSK authentication, digital certificate authentication, and ESP encrypted transmission
・Supports SON, remote management, and TR069 network management functions
・Support AC/DC power supply
・Antennas can be installed externally or in an integrated manner
The NR distributed small cell is a compact size, high power outdoor or low power indoor digital distributed base station that connects to the mobile core network through fixed broadband or dedicated backhaul. It consists of a main baseband unit (BBU), an extension unit (EU), and a remote radio unit (RRU), supporting main frequency n40/n41/n48/n77/n78/n79 achieving quick deployment and network construction, providing 5G mobile communication signal coverage for outdoor or indoor environments, achieving precise deep and capacity coverage with low cost, which enhances the data service internet experience while offloading traffic from the macro network.
HIGHLIGHTS
・Supports GPS/1588V2/1pps+TOD synchronization.
・Each cell supports at least 200 RRC active users and up to 1200 RRC connected users.
・Supports multiple IP network backhaul solutions such as xPON/PTN/IPRAN
・Supports IPSec Backhaul.
・Supports SON, remote management, and TR069 network management functions
・Support AC/DC power supply
・Antennas can be installed externally or in an integrated manner
The LTE+NR distributed base station is a hybrid solution designed for both outdoor and indoor environments, combining 4G LTE reliability with 5G NR high-speed capabilities. It connects to the mobile core network via fixed broadband or dedicated backhaul, ensuring flexible and cost-efficient deployment. The system comprises a centralized baseband unit (BBU), an extension unit (EU) for signal distribution, and remote radio units (RRUs) for localized coverage, supporting key LTE bands (e.g.,B3/B7/B40) and 5G NR frequencies (n41/n78/n79) to meet global spectrum requirements.
This architecture enables seamless coexistence of LTE and NR technologies, allowing dynamic resource sharing and smooth migration from 4G to 5G. By deploying RRUs strategically, it delivers precise deep coverage and enhanced capacity in challenging environments like urban hotspots, industrial facilities, or dense indoor spaces. The hybrid design optimizes costs by leveraging existing LTE infrastructure while introducing 5G capabilities, reducing macro network congestion through intelligent traffic offloading.
The NR distributed small cell is a compact size, high power outdoor or low power indoor digital distributed base station that connects to the mobile core network through fixed broadband or dedicated backhaul. It consists of a main baseband unit (BBU), an extension unit (EU), and a remote radio unit (RRU), supporting main frequency n40/n41/n48/n77/n78/n79 achieving quick deployment and network construction, providing 5G mobile communication signal coverage for outdoor or indoor environments, achieving precise deep and capacity coverage with low cost, which enhances the data service internet experience while offloading traffic from the macro network.
HIGHLIGHTS
・Supports GPS/1588V2/1pps+TOD synchronization.
・Each cell supports at least 200 RRC active users and up to 1200 RRC connected users.
・Supports multiple IP network backhaul solutions such as xPON/PTN/IPRAN
・Supports IPSec Backhaul.
・Supports SON, remote management, and TR069 network management functions
・Support AC/DC power supply
・Antennas can be installed externally or in an integrated manner
The NR distributed small cell is a compact size, high power outdoor or low power indoor digital distributed base station that connects to the mobile core network through fixed broadband or dedicated backhaul. It consists of a main baseband unit (BBU), an extension unit (EU), and a remote radio unit (RRU), supporting main frequency n40/n41/n48/n77/n78/n79 achieving quick deployment and network construction, providing 5G mobile communication signal coverage for outdoor or indoor environments, achieving precise deep and capacity coverage with low cost, which enhances the data service internet experience while offloading traffic from the macro network.
The LTE+NR distributed base station is a hybrid solution designed for both outdoor and indoor environments, combining 4G LTE reliability with 5G NR high-speed capabilities. It connects to the mobile core network via fixed broadband or dedicated backhaul, ensuring flexible and cost-efficient deployment. The system comprises a centralized baseband unit (BBU), an extension unit (EU) for signal distribution, and remote radio units (RRUs) for localized coverage, supporting key LTE bands (e.g.,B3/B7/B40) and 5G NR frequencies (n41/n78/n79) to meet global spectrum requirements.
This architecture enables seamless coexistence of LTE and NR technologies, allowing dynamic resource sharing and smooth migration from 4G to 5G. By deploying RRUs strategically, it delivers precise deep coverage and enhanced capacity in challenging environments like urban hotspots, industrial facilities, or dense indoor spaces. The hybrid design optimizes costs by leveraging existing LTE infrastructure while introducing 5G capabilities, reducing macro network congestion through intelligent traffic offloading."
The LTE+NR distributed base station is a hybrid solution designed for both outdoor and indoor environments, combining 4G LTE reliability with 5G NR high-speed capabilities. It connects to the mobile core network via fixed broadband or dedicated backhaul, ensuring flexible and cost-efficient deployment. The system comprises a centralized baseband unit (BBU), an extension unit (EU) for signal distribution, and remote radio units (RRUs) for localized coverage, supporting key LTE bands (e.g.,B3/B7/B40) and 5G NR frequencies (n41/n78/n79) to meet global spectrum requirements.
This architecture enables seamless coexistence of LTE and NR technologies, allowing dynamic resource sharing and smooth migration from 4G to 5G. By deploying RRUs strategically, it delivers precise deep coverage and enhanced capacity in challenging environments like urban hotspots, industrial facilities, or dense indoor spaces. The hybrid design optimizes costs by leveraging existing LTE infrastructure while introducing 5G capabilities, reducing macro network congestion through intelligent traffic offloading.
The LTE+NR distributed base station is a hybrid solution designed for both outdoor and indoor environments, combining 4G LTE reliability with 5G NR high-speed capabilities. It connects to the mobile core network via fixed broadband or dedicated backhaul, ensuring flexible and cost-efficient deployment. The system comprises a centralized baseband unit (BBU), an extension unit (EU) for signal distribution, and remote radio units (RRUs) for localized coverage, supporting key LTE bands (e.g.,B3/B7/B40) and 5G NR frequencies (n41/n78/n79) to meet global spectrum requirements.
This architecture enables seamless coexistence of LTE and NR technologies, allowing dynamic resource sharing and smooth migration from 4G to 5G. By deploying RRUs strategically, it delivers precise deep coverage and enhanced capacity in challenging environments like urban hotspots, industrial facilities, or dense indoor spaces. The hybrid design optimizes costs by leveraging existing LTE infrastructure while introducing 5G capabilities, reducing macro network congestion through intelligent traffic offloading.
HIGHLIGHTS
・Support GPS,RGPS, 1588 synchronization
・Supports 96 user access status and 84 user VOLTE, providing voice, video, data and mobile communication services for terminals
・Supports multiple IP network backhaul solutions such as xPON/PTN/IPRAN
・Supports PSK authentication, digital certificate authentication, and ESP encrypted transmission
・Supports SON, remote management, and TR069 network management functions
・Support AC 220V to DC +12V power adapter supply
・Antennas can be installed externally or in an integrated manner
・Security control
HIGHLIGHTS
・Support GPS,RGPS, 1588 synchronization
・Supports 64 user access status and 32 user VOLTE, providing voice, video, data and mobile communication services for terminals
・Supports multiple IP network backhaul solutions such as xPON/PTN/IPRAN
・Supports PSK authentication, digital certificate authentication, and ESP encrypted transmission
・Supports SON, remote management, and TR069 network management functions
・Support AC 220V to DC -48V
・Security control
HIGHLIGHTS
・ALL-IN-ONE plug-and-play integrated small cell with a combined baseband and RF design.
・Supports flat network architecture with a variety of backhaul interfaces, including IP backhaul for public transmission.
・Network management support, enabling device management, monitoring, and maintenance through network management system.
・Compatible with multiple synchronization methods, including GPS and 1588V2.
・Supports frequency bands n41/n48/n77/n78/n79.
・Capable of supporting 200 active users, 400 connected users, and 200 VONR users.
・Antennas can be installed externally or in an integrated manner
・Support AC 220V to DC +12V power adapter supply
HIGHLIGHTS
・Supports flat network architecture with various backhaul interfaces, including IP backhaul for public transmission.
・Provides network management functions, enabling device management, monitoring, and maintenance within the network management system.
・Supports multiple synchronization methods, including GPS and 1588V2.
・Offers selectable frequency bands, including n41, n48, n77, n78, and n79.
・Supports 128 active service users, 256 connected users, and 128 VoNR users.
・Antennas can be installed externally or in an integrated manner
・Support AC 220V to DC +12V power adapter supply
XXXX Pol Panel Antenna 698-960/3×1710-2690MHz 65°/65 16/18dBi 0°-10° Replaceable RET
XXXX Pol Panel Antenna 698-960/3×1710-2690MHz 65°/65° 16.5/18dBi 2°-12°/0°-10° Replaceable RET
XXX Pol Panel Antenna 698-960/2×1710-2690MHz 65°/65° 17/18dBi 0°-10°Replaceable RET
XXX Pol Panel Antenna 698-960/2×1710-2690MHz 65°/65° 15.5/18dBi 2°-12°/2°-12° Replaceable RET
XX Pol Panel Antenna 2×1710-2690MHz 65° 15dBi 2°-12° Replaceable RET
X Pol Panel Antenna 698-960MHz 33° 19.5dBi 2°-12° Replaceable RET
XXXX Pol Panel Antenna 2×1710-2170/2×2490-2690MHz 65° 16/17dBi 2-12°/2-12° Replaceable RET
XXXXX Pol Panel Antenna 694-960/2×1710-2690/2×1710-2690MHz 65°/65°/65° 16/16.5/16dBi 0°-10°/0°-10°/0°-10° Replaceable RET
XX Pol Panel Antenna 2×1710-2690MHz 65° 19dBi 0°-8° Replaceable RET
XX Pol Panel Antenna 2×1710-2690MHz 65° 17dBi 2°-12°Replaceable RET
XXXX Pol Panel Antenna 2×698-960/2×1710-2690MHz 65°/65° 17/17.5dBi 2°-12°/2°-12° Replaceable RET
XXXXXX Pol Panel Antenna 2×698-960/4×1710-2690MHz 65°/65° 17/17.5dBi 2°-12°/2°-12° Replaceable RET
XXXXXX Pol Panel Antenna 2×698-960/4×1710-2690MHz 65°/65° 14/17.5dBi 2°-12°/2°-12° Replaceable RET
XXXXXX Pol Panel Antenna 2×698-960/4×1710-2690MHz 65°/65° 15.5/18dBi 2-12°/2-12° Replaceable RET
XXXX Pol Panel Antenna 2×698-960/2×1710-2690MHz 65°/65° 15.5/17.5dBi 2°-12°/2°-12° Replaceable RET
XXX Pol Panel Antenna 2×698-960/1710-2690MHz 65°/65° 17/17.5dBi 2°-12°/2°-12° Replaceable RET
XXX Pol Panel Antenna 2×698-960/1710-2690MHz 65°/65° 15.5/17.5dBi 2°-12°/2°-12° Replaceable RET
X Pol Panel TD Antenna 2500-2690MHz 65° 14.5dBi 2°-12° Replaceable RET
XXXXXX Pol Panel Antenna 2×698-960/2×1710-2170/2×2500-2690MHz 65°/65°/65° 15/16.5/17dBi 2°-12°/2°-12°/2°-12° Replaceable RET
X Pol Panel TD Antenna 2300-2690MHz 90° 15.5dBi 2°-12° Replaceable RET
XXXXXX Pol 2×698-960/4×1710-2690MHz 65°/65° 16/18dBi 2°-12°/2°-12° Replaceable RET
X Pol Panel TD Antenna 3300-3800MHz 65° 15dBi 2°-12° Replaceable RET
XXXXXX Pol 2×698-960/4×1710-2690MHz 65°/65° 14/14.5dBi 2°-12°/2°-12° Replaceable RET
X Pol Panel TD Antenna 3300-3800MHz 80° 14dBi 2°-12° Replaceable RET
XXXXXX Pol 2×698-960/4×1710-2690MHz 65°/65° 12/14dBi 2°-16°/2°-12° Replaceable RET
XXXX Pol Dual Band Twin Beam Antenna 2×698-960/2×1710-2690MHz 33°/32° 16.5/19.5dBi 2°-12°/2°-12° Replaceable RET
XX Pol Twin Beam Panel Antenna 2×1710-2690MHz 32° 20dBi 2-12°Replaceable RET
6X Pol Panel Triple Beam Antenna 2×3×1710-2690MHz 22°20/20/20dBi 2°-12°Replaceable RET
XXX Pol Panel Triple Beam Antenna 3×1710-2690MHz 18°21/22/21dBi 2-12°Replaceable RET
XXX Pol Panel Triple Beam Antenna 3×1710-2690MHz 16° 19.5 dBi 6° FET
XX Pol Panel Twin Beam Antenna 2×698-960MHz 35° 18dBi 0°-10° Replaceable RET
XXX Pol Panel Triple Beam Antenna 3×1710-2690MHz 18°21/22/21dBi 2-10° RET 4.3-10 connecter
XXX Pol Panel Stadium Antenna 790-960/1710-2170/2300-2690MHz 50°/50°/50° 10.5/9.5/9.0dBi 0° FET
XX Pol Panel Stadium Antenna 2×1710-2690MHz 50°10dBi 0°FET
XXXX Pol Panel Stadium Antenna 790-960/1710-2690/3300-3800/3300-3800MHz 50°/50°/50°/50° 11.5/11.5/9.5/9.5dBi 0° FET
X Pol Panel Stadium Antenna 1710-2690MHz 50° 11dBi 0° FET
XX Pol Panel Stadium Antenna 3300-3800MHz 50° 10dBi 0° FET
3XXX Pol Tube Antenna 3×698-960/6×1710-2690MHz 65°/65° 14/17.5dBi 0°-10°/0°-10° Replaceable RET
3XXX Pol Tube Antenna 3×698-960/6×1710-2690MHz 65°/65° 14/17dBi 0°-10°/0°-10° RET
XXXXX Pol Panel Antenna 698-960/2×1710-2690/2×1710-2690MHz 65°/32°/32° 16/19/19dBi 2°-12° Replaceable RET
XXXXX Pol Panel Hybrid Antenna 698-960/1710-2690/1710-2690/1710-2690/1710-2690MHz 65°/65°/65°/32°/32° 16/17/17/19/19dBi 2°-12°/2°-10° Replaceable RET
XXX Pol Panel Hybrid Antenna 698-960/2×1710-2690MHz 65°/32° 16/20dBi 2-12°/ 2-10° Replaceable RET
XX Pol Panel Twin Beam Antenna 2×1710-2170MHz 35° 20dBi 0°-10° Replaceable RET
XXXX Pol Twin Beam Panel Antenna 2×1710-2690/2×1710-2690MHz 32°/32° 18.5/18.5dBi 2-10°/2-10° Replaceable RET
X Pol Panel TD Antenna 3300-3800MHz 80° 13.5dBi 2°-12° Replaceable RET
XXXXX Pol 698-960/4×1695-2690MHz 65°/65° 12/12.5dBi 3°/3° FET
XXX Pol Panel Triple Beam Antenna 3×698-960MHz 22° 18dBi 4-12° RET
XXXXX Pol Panel Penta Beam Antenna 5×694-960MHz 14° 21 dBi 6° FET
XXXX Pol Twin Beam Panel Antenna 2×1710-2690/2×1710-2690MHz 32°/32° 20/20dBi 2-12°/2-12°Replaceable RET
6X Pol Panel Triple Beam Antenna 2×3×1710-2690MHz 18° 21/22/21dBi 2°-12° Replaceable RET
6X12X Pol Panel Hexa Beam Antenna 6×1695-2690/2×6×3300-4200MHz 8°/8°22/22dBi 6°/6° FET
X Pol Panel TD Antenna 3300-3800MHz 80° 15dBi 2°-12° Replaceable RET
XXXXX Pol 698-960/4×1695-2690MHz 65°/65° 14/14dBi 2°-12°/2°-12° Replaceable RET
X Pol Panel TD Antenna 2300-2690MHz 90° 15.0dBi 2°-12° Replaceable RET
XX Pol Panel Antenna 2×690-960MHz 65° 14.0dBi 2°-12° Replaceable RET
X Pol Panel TD Antenna 3300-3800MHz 65° 13.5dBi 2°-12° Replaceable RET
XXXXXX Pol 2×698-960/4×1710-2690MHz 65°/65° 12/13dBi 3°/3° FET
X Pol Panel TD Antenna 3300-3800MHz 80°10dBi 3° FET
XXXXX Pol 698-960/4×1695-2690MHz 65°/65°10/11dBi 3° FET
XX Pol Panel Antenna 698-960/1710-2690MHz 65°/65° 11/14dBi 3°/3° FET
XX Pol Panel Antenna Diplexed 698-960/1710-2690MHz 65°/65° 10/13.5dBi 3°/3° FET
XX Pol Panel Antenna 1710-2700/3300-3800MHz 25° 15dBi 0° FET
XX Pol Panel Antenna Built-in Diplexer 698-960/1710-2690MHz 65°/65° 8/11dBi 0°/0° FET
XX Pol Panel Antenna Built-in Diplexer 698-960/1710-2690MHz 65°/65° 14/17dBi 0°-14°/0°-10°Replaceable RET
XXXX Pol Panel Antenna 694-960/2×1710-2690/1710-2690MHz 65°/65°/65° 15/16/15.5dBi 0°-10°/0°-10°/0°-10° Replaceable RET
XXXX Pol Panel Antenna 694-960/2×1710-2690/1710-2690MHz 65°/65°/65° 16/16.5/16dBi 0°-10°/0°-10°/0°-10° Replaceable RET
6X Pol Panel Triple Beam Antenna 2×3×1710-2690MHz 22°20/20/20dBi 2°-12°Replaceable RET
XXXXX Pol Panel Antenna 698-960/2×1710-2690/2×1710-2690MHz 65°/65°/65° 16/17.5/17dBi 2°-12°/2°-12°/2°-12°Replaceable RET
XXXX Pol Panel Antenna 698-960/3x1710-2690MHz 65°/65° 16/17.5dBi 0°-10°/0°-10° Replaceable RET
XXX Pol Panel Antenna 694-960/2×1710-2690MHz 33°/33° 16/20dBi 2°-12°/2°-12° Replaceable RET
XXXXXXXX Pol Panel Antenna 2×698-960/2×1710-2170/2×2490-2690/2×1710-2690MHz 65°/65°/65°/65° 15/16/16/17dBi 2°-12°/2°-12°/2°-12°/2°-12° Replaceable RET
XXXXXXXX Pol Panel Antenna 2×698-960/6×1710-2690MHz 65°/65° 17/17.5dBi 2-12° Replaceable RET
XXXXXX Pol Panel Antenna 2×698-960/2×1710-2170/2×2490-2690MHz 65°/65°/65° 15.5/16/16.5dBi 0°-10°/0°-10°/0°-10°Replaceable RET 4.3-10 Connector
XXXXXXXX Pol Panel Antenna 2×694-960/2×1710-2170/2×2490-2690/2×1710-2690MHz 65°/65°/65°/65° 13/16.5/17/16.5dBi 2°-16°/2°-12°/2°-12°/2°-12° Replaceable RET
XXXXXX Pol Panel Antenna 2×1710-2170/2×2500-2690/2×2500-2690MHz 65°/65°/65° 16.5/17/17dBi 0°-10°Replaceable RET 4.3-10 Connector
XXXXX Pol Panel Antenna 694-960/2×1710-2690/2×1710-2690MHz 65°/65°/65° 15/15.5/16dBi 0°-10°/0°-10°/0°-10° Replaceable RET
XX Pol Panel Antenna 1710-2690/1710-2690MHz 65°/65° 15/15dBi 0° FET 4.3-10 Connector
XX Pol Panel Antenna 1710-2690/1710-2690MHz 65°/65° 12/12dBi 6° FET
X Pol Panel Antenna 1710-2690MHz 33° 14dBi 0° Fixed Tilt 4.3-10 Connector
X Pol Panel Antenna 698-960MHz 90° 15.5dBi 0-10°Replaceable RET
XX Pol Panel Antenna 2×1710-2690MHz 33° 19dBi 0°-10°Replaceable RET
XXXXXX Pol Panel Antenna 2×698-960/4×1695-2690MHz 65°/65° 12/14dBi 3°/3° FET
XXXXXX Pol Panel Antenna 2×698-960/4×1710-2690MHz 65°/65° 14/18dBi 0-14°/0-10° Replaceable RET
XDAS is a solution for transmitting and distributing wireless signals through optical fibers. This system fully utilizes the advantages of large bandwidth and low transmission loss of optical fibers, and adapts to the network construction needs of multiple operators and services. It is an effective distributed system construction solution that integrates multiple standards and services.System Overview.
XDAS is a solution for transmitting and distributing wireless signals through optical fibers. This system fully utilizes the advantages of large bandwidth and low transmission loss of optical fibers, and adapts to the network construction needs of multiple operators and services. It is an effective distributed system construction solution that integrates multiple standards and services.System Overview.
The solution of 5G new frequency shift IBS is aimed to upgrade the existing single-cable passive DAS into 5G DAS. New 5G indoor distributed signal can overlay on the existing passive feeder network. This approach is widely used in global CSP 5G DAS deployment.
FDD-LTE femtocell base station system, equipped with 2*125mW/2*250mW RF remote head end. The femtocell is connected to the EPC core network through IPsec (IPRAN), and the system adopts a star network architecture to provide FDD-LTE 4G services to users.
Integrated outdoor high-power base station system, equipped with 2*5W/2*20W/2*40W RF remote head end. The Integrated base station is connected to the EPC core network through IPsec (IPRAN), and the system adopts a star network architecture to provide FDD-LTE 4G services to users.
